Lattice Boltzmann Method for One-dimensional Riesz Spatial Fractional Convection-Diffusion Equations

doi:10.19596/j.cnki.1001-246x.8318

Abstract

Abstract:

A D1Q3 evolution model of lattice Boltzmann method (LBM) is established to numerically solve a class of spatial fractional convection-diffusion equation in Riesz sense. By discretizing the integral term of fractional order operator, the fractional convection-diffusion equation is transformed into a standard one with Riesz derivative. With Taylor expansion, Chapman-Enskog and multi-scales expansion, equilibrium distribution functions of the model are derived in all directions. Furthermore, the macroscopic equation to be solved is recovered correctly. Finally, numerical experiments are carried out to verify the model.

Key words: Riesz spatial fractional convection-diffusion equation, lattice Boltzmann method, Chapman-Enskog expansion

CLC Number:

O241.82

Xuedan WEI, Houping DAI, Mengjun LI, Zhoushun ZHENG. Lattice Boltzmann Method for One-dimensional Riesz Spatial Fractional Convection-Diffusion Equations[J]. Chinese Journal of Computational Physics, 2021, 38(6): 683-692.

Figures/Tables 15

References 32

1	SAICHEV A I, ZASLAVSKY G M. Fractional kinetic equations: Solutions and applications[J]. Chaos: An Interdisciplinary Journal of Nonlinear Science, 1997, 7 (4): 753- 764. DOI
2	ZASLAVSKY G M. Chaos, fractional kinetics, and anomalous transport[J]. Physics Reports, 2002, 371 (6): 461- 580. DOI
3	MEERSCHAERT M M, BENSON D A, BAEUMER B. Operator Lévy motion and multiscaling anomalous diffusion[J]. Physical Review E, 2001, 63 (2): 021112. DOI
4	YUSTE S B, ACEDO L, LINDENBERG K. Reaction front in an A+B→C reaction-subdiffusion process[J]. Physical Review E, 2004, 69 (3): 036126. DOI
5	SCALAS E, GORENFLO R, MAINARDI F. Fractional calculus and continuous-time finance[J]. Physica A: Statistical Mechanics and Its Applications, 2000, 284 (1-4): 376- 384. DOI
6	RABERTO M, SCALAS E, MAINARDI F. Waiting-times and returns in high-frequency financial data: An empirical study[J]. Physica A: Statistical Mechanics and Its Applications, 2002, 314 (1-4): 749- 755. DOI
7	LIU F, ANH V, TURNER I. Numerical solution of the space fractional Fokker-Planck equation[J]. Journal of Computational and Applied Mathematics, 2004, 166 (1): 209- 219. DOI
8	MOMANI S, ODIBAT Z. Numerical solutions of the space-time fractional advection-dispersion equation[J]. Numerical Methods for Partial Differential Equations: An International Journal, 2008, 24 (6): 1416- 1429. DOI
9	MEERSCHAERT M M, TADJERAN C. Finite difference approximations for fractional advection-dispersion flow equations[J]. Journal of Computational and Applied Mathematics, 2004, 172 (1): 65- 77. DOI
10	LIU Q, LIU F, TURNER I. Approximation of the Lévy-Feller advection-dispersion process by random walk and finite difference method[J]. Journal of Computational Physics, 2007, 222 (1): 57- 70. DOI
11	ZHUANG P, LIU F, ANH V. Numerical methods for the variable-order fractional advection-diffusion equation with a nonlinear source term[J]. SIAM Journal on Numerical Analysis, 2009, 47 (3): 1760- 1781. DOI
12	曾宝思, 尹修草, 谢常平, 等. 带Robin边界条件的分数阶对流-扩散方程的数值解法[J]. 四川大学学报(自然科学版), 2018, 55 (1): 13- 17.
13	YANG Q, LIU F, TURNER I. Numerical methods for fractional partial differential equations with Riesz space fractional derivatives[J]. Applied Mathematical Modelling, 2010, 34 (1): 200- 218. DOI
14	陈传军, 赵鑫. 一类非线性对流扩散方程两重网格特征有限元方法及误差估计[J]. 数学物理学报, 2014, 34 (3): 643- 654.
15	ZHU X, NIE Y, WANG J. A characteristic finite element method for fractional convection-diffusion equations[J]. Chinese Journal of Computational Physics, 2017, 34 (4): 417- 424.
16	CARELLA A R L, DORAO C A. Least-squares spectral method for the solution of a fractional advection-dispersion equation[J]. Journal of Computational Physics, 2013, 232 (1): 33- 45. DOI
17	ZHENG Z, LIU Z, GENG T. A fractional model of metal fiber sintering process[J]. Chinese Journal of Computational Physics, 2019, 36 (5): 595- 602.
18	JU L, ZHANG C, CHEN S. Lattice Boltzmann study on displacement process of thermal miscible fluids in porous media[J]. Chinese Journal of Computational Physics, 2019, 36 (6): 648- 658.
19	WALTHER E, BENNACER R, DE CAROLINE S. Lattice Boltzmann method and diffusion in materials with large diffusivity ratios[J]. Thermal Science, 2017, 21 (3): 1173- 1182. DOI
20	刘艳红, 闫广武. 某些电磁波传播问题的格子Boltzmann模拟[J]. 吉林大学学报(理学版), 2019, 57 (2): 271- 276.
21	LAI H, MA C. Lattice Boltzmann method for the generalized Kuramoto-Sivashinsky equation[J]. Physica A: Statistical Mechanics and Its Applications, 2009, 388 (8): 1405- 1412. DOI
22	CHAI Z, SHI B, GUO Z. A multiple-relaxation-time lattice Boltzmann model for general nonlinear anisotropic convection-diffusion equations[J]. Journal of Scientific Computing, 2016, 69 (1): 355- 390. DOI
23	CHAI Z, HE N, GUO Z, et al. Lattice Boltzmann model for high-order nonlinear partial differential equations[J]. Physical Review E, 2018, 97 (1): 013304. DOI
24	CHAI Z, SHI B. Multiple-relaxation-time lattice Boltzmann method for the Navier-Stokes and nonlinear convection-diffusion equations: Modeling, analysis, and elements[J]. Physical Review E, 2020, 102 (2): 023306.
25	DU R, SUN D, SHI B, et al. Lattice Boltzmann model for time sub-diffusion equation in Caputo sense[J]. Applied Mathematics and Computation, 2019, 358, 80- 90. DOI
26	DU R, LIU Z. A lattice Boltzmann model for the fractional advection-diffusion equation coupled with incompressible Navier-Stokes equation[J]. Applied Mathematics Letters, 2020, 101, 106074. DOI
27	LIANG H, ZHANG C, DU R, et al. Lattice Boltzmann method for fractional Cahn-Hilliard equation[J]. Communications in Nonlinear Science and Numerical Simulation, 2020, 91, 105443. DOI
28	DELLACHERIE S. Construction and analysis of lattice Boltzmann methods applied to a 1D convection-diffusion equation[J]. Acta Applicandae Mathematicae, 2014, 131 (1): 69- 140. DOI
29	戴厚平, 郑洲顺, 段丹丹. 变系数反应扩散方程的格子Boltzmann模型[J]. 云南大学学报(自然科学版), 2016, 38 (4): 524- 529.
30	ZHOU J G, HAYGARTH P M, WITHERS P J A. Lattice Boltzmann method for the fractional advection-diffusion equation[J]. Physical Review E, 2016, 93 (4): 043310. DOI
31	LI X, ZHAO Y, HU Z, et al. Investigation of normal shock structure by using Navier-Stokes equations with the second viscosity[J]. Chinese Journal of Computational Physics, 2020, 37 (5): 505- 513.
32	易倩. 分数阶对流方程及相关问题的有限差分方法[D]. 上海: 上海大学, 2019.

T	GRE	CPU/s
0.1	8.360 8×10^-4	0.12
0.3	2.485 3×10^-3	0.18
0.5	4.089 1×10^-3	0.23
0.8	6.427 8×10^-3	0.31
1	7.948 4×10^-3	0.37

T	GRE	CPU/s
0.1	8.360 8×10^-4	0.12
0.3	2.485 3×10^-3	0.18
0.5	4.089 1×10^-3	0.23
0.8	6.427 8×10^-3	0.31
1	7.948 4×10^-3	0.37

β	GRE
0.1	8.663 6×10^-4
0.3	7.875 1×10^-4
0.5	7.128 5×10^-4
0.7	6.365 5×10^-4
0.9	5.634 8×10^-4

β	GRE
0.1	8.663 6×10^-4
0.3	7.875 1×10^-4
0.5	7.128 5×10^-4
0.7	6.365 5×10^-4
0.9	5.634 8×10^-4

T	GRE	MAE
0.1	7.335 1×10^-4	2.310 2×10^-6
0.2	2.097 0×10^-3	8.476 8×10^-6
0.4	4.735 2×10^-3	7.851 2×10^-5
0.8	9.664 9×10^-3	5.866 0×10^-4
1.6	1.912 3×10^-3	4.466 4×10^-3
