Chinese Journal of Computational Physics ›› 2021, Vol. 38 ›› Issue (6): 707-712.DOI: 10.19596/j.cnki.1001-246x.8333
• Research Reports • Previous Articles Next Articles
Yuanqiang ZHU1,2(), Saisai JIN1, Qingqing SUN1
Received:
2021-01-18
Online:
2021-11-25
Published:
2022-04-27
CLC Number:
Yuanqiang ZHU, Saisai JIN, Qingqing SUN. Adsorption Characteristics of N2 on Shale Kerogen[J]. Chinese Journal of Computational Physics, 2021, 38(6): 707-712.
Add to citation manager EndNote|Ris|BibTeX
URL: http://www.cjcp.org.cn/EN/10.19596/j.cnki.1001-246x.8333
构型 | 吸附能E/(kJ·mol-1) | 构型 | 吸附能E/(kJ·mol-1) | |
C_A | 9.857 | C_B | 9.831 | |
C_C | 9.630 | C_D | 8.134 | |
C_E | 9.177 | |||
N-C_A | 9.146 | N-C_B | 9.524 | |
N-C_C | 9.685 | N-C_D | 8.907 |
Table 1 Adsorption energy of N2 on kerogen C28H14O and N-doped kerogen C27H14ON
构型 | 吸附能E/(kJ·mol-1) | 构型 | 吸附能E/(kJ·mol-1) | |
C_A | 9.857 | C_B | 9.831 | |
C_C | 9.630 | C_D | 8.134 | |
C_E | 9.177 | |||
N-C_A | 9.146 | N-C_B | 9.524 | |
N-C_C | 9.685 | N-C_D | 8.907 |
构型 | CHelpG(Δq) | MK(Δq) | 构型 | CHelpG(Δq) | MK(Δq) | |
C_A | -0.032 092 | -0.008 584 | C_B | -0.032 886 | -0.008 587 | |
C_C | -0.033 062 | -0.010 621 | C_D | -0.031 442 | -0.013 607 | |
C_E | -0.029 809 | -0.008 745 | ||||
N-C_A | -0.031 154 | -0.006 188 | N-C_B | -0.032 631 | -0.009 709 | |
N-C_C | -0.031 080 | -0.006 393 | N-C_D | -0.024 852 | -0.005 012 |
Table 2 CHelpG and MK charge transfer between N2 and kerogen C28H14O and N-doped kerogen C27H14ON
构型 | CHelpG(Δq) | MK(Δq) | 构型 | CHelpG(Δq) | MK(Δq) | |
C_A | -0.032 092 | -0.008 584 | C_B | -0.032 886 | -0.008 587 | |
C_C | -0.033 062 | -0.010 621 | C_D | -0.031 442 | -0.013 607 | |
C_E | -0.029 809 | -0.008 745 | ||||
N-C_A | -0.031 154 | -0.006 188 | N-C_B | -0.032 631 | -0.009 709 | |
N-C_C | -0.031 080 | -0.006 393 | N-C_D | -0.024 852 | -0.005 012 |
1 | DING M C, WU M L, LI X, et al. Characteristics of transient pressure for multiple fractured horizontal wells in fractal fractured shale gas reservoirs[J]. Chinese Journal of Computational Physics, 2019, 36 (5): 559- 568. |
2 | 霍培丽, 张登峰, 王倩倩, 等. 页岩吸附性能及作用规律[J]. 化工进展, 2016, 35 (1): 74- 82. |
3 | 张莉, 熊永强, 陈媛, 等. 中国典型海相富有机质页岩的生气机理[J]. 地球科学, 2017, 42 (7): 1092- 1106. |
4 | DU D F, WANG Y Y, FU J G, et al. Shale gas seepage mechanism and transient pressure analysis[J]. Chinese Journal of Computational Physics, 2015, 32 (1): 51- 57. |
5 | YANG Q, QIAN Y, WANG Y, et al. Development of an oil shale retorting process integrated with chemical looping for hydrogen production[J]. Industrial & Engineering Chemistry Research, 2015, 54 (23): 6156- 6164. |
6 | ZHANG T, ELLIS G S, RUPPEL S C, et al. Effect of organic-matter type and thermal maturity on methane adsorption in shale-gas systems[J]. Organic Geochemistry, 2012, 47 (6): 120- 131. |
7 | ETMINAN S R, JAVADPOUR F, MAINI B B, et al. Measurement of gas storage processes in shale and of the molecular diffusion coefficient in kerogen[J]. International Journal of Coal Geology, 2014, 123 (1): 10- 19. |
8 |
YU H, XU H, FAN J, et al. Roughness factor-dependent transport characteristic of shale gas through amorphous kerogen nanopores[J]. The Journal of Physical Chemistry C, 2020, 124 (23): 12752- 12765.
DOI |
9 | 郭宇航, 刘财, 潘保芝, 等. 基于岩石物理参数转换模型的页岩气含气量评价新方法研究[J]. 地球物理学报, 2019, 62 (7): 2724- 2731. |
10 | ROGALA A, KRZYSIEK J, BERNACIAK J, et al. Non-aqueous fracturing technologies for shale gas recovery[J]. Physicochemical Problems of Mineral Processing, 2013, 49 (1): 313- 322. |
11 |
HAO F, ZOU H, LU Y. Mechanisms of shale gas storage: Implications for shale gas exploration in China[J]. AAPG Bulletin-American Association of Petroleum Geologists, 2013, 97 (8): 1325- 1346.
DOI |
12 |
DENNEY D. Carbon dioxide storage capacity of organic-rich shales[J]. Journal of Petroleum Technology, 2011, 63 (7): 114- 117.
DOI |
13 | LIU B, SHI J Q, SHEN Y, et al. A molecular dynamics simulation of methane adsorption in graphite slit-pores[J]. Chinese Journal of Computational Physics, 2013, 30 (5): 692- 699. |
14 | ZHU Y Q, SU H, JING Y, et al. Methane adsorption on the surface of a model of shale: A density functional theory study[J]. Applied Surface Science, 2016, 387 (30): 379- 384. |
15 | 石基弘, 陈诚, 巩亮, 等. 甲烷在干酪根中的吸附及扩散特性[J]. 工程热物理, 2019, 40 (6): 1338- 1343. |
16 | 隋红光, 姚军. CO2/CH4在干酪根中竞争吸附的分子模拟[J]. 科学技术与工程, 2016, 16 (11): 128- 131. |
17 | HUANG L, NING Z, WANG Q, et al. Molecular insights into kerogen deformation induced by CO2/CH4 sorption: Effect of maturity and moisture[J]. Energy Fuel, 2019, 33 (6): 4792- 4805. |
18 | WANG T, TIAN S, LI G, et al. Selective adsorption of supercritical carbon dioxide and methane binary mixture in shale kerogen nanopores[J]. Journal of Natural Gas Science and Engineering, 2018, 50 (1): 181- 188. |
19 | HUANG L, NING Z, WANG Q, et al. Effect of organic type and moisture on CO2/CH4 competitive adsorption in kerogen with implications for CO2 sequestration and enhanced CH4 recovery[J]. Appled Energy, 2018, 210 (1): 28- 43. |
20 | LIU F, ELLETT K, XIAO Y, et al. Assessing the feasibility of CO2 storage in the New Albany Shale(Devonian-Mississippian) with potential enhanced gas recovery using reservoir simulation[J]. International Journal of Greenhouse Gas Control, 2013, 17 (1): 111- 126. |
21 | PRIBYLOV A A, SKIBITSKAYA N A. Sorption of methane, ethane, propane, butane, carbon dioxide, and nitrogen on kerogen[J]. Russian Journal of Physical Chemistry A, 2014, 88 (6): 1028- 1036. |
22 | 刘向君, 罗丹序, 熊健, 等. 龙马溪组页岩干酪根平均分子结构模型的构建[J]. 化工进展, 2017, 36 (2): 530- 537. |
